Schmersal 101189041 Magnetic Reed Switch 3A BP 10 Screw Terminal

Product Code: 101189041

  • Rated for 250 VAC and 3 A
  • Durable die-cast light alloy housing
  • IP67 protection for harsh environments
  • Operates in -25 to 70°C temperature range
  • Magnetic drive switching with reed contacts
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Maximum Temperature (°C) 85
Minimum Temperature (°C) -40
Rated Minimum Operational Voltage DC (V) 10
Rated Maximum Operational Voltage DC (V) 49
Product Type Magnetic Reed Switch
Brand SCHMERSAL
Series NT24K
Accuracy 0.3 mm
Actuating Element Magnet
Actuating Speed 18 m/s
Bounce Duration 0.3 ms
Control Element Reed Contacts
Degree of Protection IP67
Housing Material Die Cast Light Alloy, Painted
Mechanical Life 1000000000 Operations
Operational Temperature -25 to 70 deg C
Rated Current 3 A
Rated Voltage 250 VAC
Resistance 10-55 Hz
Standards and Approvals EN IEC 60079-0, EN IEC 60079-15, EN 60079-31
Switching Capacity 120 W
Switching Type Magnetic Drive

Description

Optimize your industrial network with the Schmersal NT24K Series Ethernet Switch, designed for hazardous environments. This robust 14-port managed switch features eight RJ-45 ports supporting 10/100/1000BaseT and six ST or SC duplex fiber ports compatible with 100BaseFX. It's equipped for long-distance communication with a singlemode fiber length of up to 40km and ST style connectors. The unit ensures reliable operation in demanding conditions with a power input range of 10-49 VDC and a maximum input current of 750 mA at 24 VDC. Ideal for applications requiring precise magnetic reed switch functionality, this Ethernet switch is engineered to maintain network integrity in challenging industrial settings.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
