Schmersal 101214278 EX Belt Alignment Switch Plastic Reinforced Glass Fibre

Product Code: 101214278

  • Belt alignment switch for precise monitoring
  • Operates at 22-49 VDC efficiently
  • Durable plastic, reinforced glass fibre housing
  • IP20 protection against solid objects
  • Long mechanical life of 30 million operations
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Maximum Temperature (°C) 80
Minimum Temperature (°C) -40
Minimum Ambient Temperature (°C) -30
Standards EN IEC 60947-5-1 / EN ISO 13849-1 / BG-GS-ET-15
Sensor Length (mm) 16.6
EAN 4030660000000
eCl@ss Number, Version 9.0 27-27-06-09
Sensor Height (mm) 139
ETIM 7.0 EC002593
ETIM 6.0 EC000030
eCl@ss Number, Version 11.0 27-27-06-09
Minimum Mechanical Life 30000000 Operations
Gross Weight (g) 338
Utilisation Category AC-15 240 VAC
Utilisation Category DC-13 24 VDC
Net Weight (g) 382
Rated Minimum Operational Voltage DC (V) 22
Rated Maximum Operational Voltage DC (V) 49
Enclosure Material Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
Maximum Ambient Temperature (°C) 50
Product Type EX Belt Alignment Switch
Brand SCHMERSAL
Series NT24k
Degree of Protection IP20
Housing Material Plastic, Reinforced Glass Fibre
Mechanical Life 30000000 Operations
Rated Voltage 22-49 VDC
Standards and Approvals BG-GS-ET-15, ENIEC 60947-5-1, ENISO 13849-1
Terminal Type Cable, 4 Pole
Weight 382 g

Description

Optimize your industrial network performance with the Schmersal NT24K Series Belt Alignment Switch. This robust 14-Port Gigabit Managed POE+ Ethernet Switch is engineered for hazardous area applications, ensuring reliable connectivity and safety. It features eight RJ-45 ports supporting 10/100/1000BaseT and six duplex fiber ports compatible with both ST or SC connectors for singlemode fiber with a reach of up to 40km. Designed to withstand demanding conditions, it operates on a power input range of 22-49 VDC and can handle a maximum input current of 11.24 A at 24 VDC. Perfect for mission-critical systems requiring long-distance, high-speed communications, this switch is an essential component in maintaining seamless operations within challenging environments.
