The Ex-T335 series is a robust and reliable choice for industrial and commercial applications, designed to meet demanding requirements with precision. This product stands out with its rated voltage of 230 VAC and a current rating of 4 A, making it suitable for various electrical systems. Its contact configuration of 1NO+1NC provides flexibility in circuit design, allowing for both normally open and normally closed operations.
A notable feature is the mechanical life expectancy of up to one million cycles, ensuring longevity and reducing the need for frequent replacements. The housing is crafted from die-cast zinc metal, offering durability while maintaining a lightweight profile at just 400 grams. With an IP67 degree of protection, this unit can withstand dust ingress and temporary submersion in water, making it ideal for harsh environments.
Operating efficiently within temperatures ranging from -20 to 60 degrees Celsius, the Ex-T335 series adapts well to diverse climatic conditions found across Australia. Its slow action mechanism ensures precise control over operations without sudden changes that could affect system stability.
Safety standards are paramount with compliance to numerous certifications including ATEx, CCC-Ex, cULus, EC000030 among others like EN 60079-1 and IECEx which verify its suitability in explosive atmospheres. Additionally, it meets EN IEC 60079-0 standards ensuring global acceptance.
The sensor dimensions are compact at 60.6 mm length by 40.5 mm width by 134 mm height allowing easy integration into existing setups without requiring extensive modifications or space considerations. Contact material made from silver enhances conductivity while supporting high insulation voltage up to 500 V.
In summary, the Ex-T335 series offers a sturdy solution tailored for those seeking reliability combined with adherence to international safety norms in their electrical installations.
