Schmersal 101160083 Position Switch 250VAC 1NO+1NC

Product Code: 101160083

Rated for 250 VAC and 4 A
Durable aluminium housing, IP65 protection
Operates from -40 to 200°C
Snap action with roller plunger
Long mechanical life: 5 million cycles

Specifications

Ambient Temperature Range (°C)	-40 to 200
Working Principle	Mechanical
Sensor Length (mm)	63
Sensor Width (mm)	106
Sensor Height (mm)	145
Minimum Mechanical Life	5,000,000 Operations
Gross Weight (g)	620
Product Type	Position Switch
Brand	SCHMERSAL
Action	Snap Action
Actuating Element	Roller Plunger
Actuating Speed	0.5 m/s
Contact Configuration	1NO+1NC
Contact Material	Silver
Degree of Protection	IP65
Housing Material	Aluminium
Mechanical Life	5000000 Cycles
Operational Temperature	-40 to 200 deg C
Rated Current	4 A
Rated Insulation Voltage	400 V
Rated Voltage	250 VAC
Sensor Size	63 mm L x 106 mm W x 145 mm H
Standards and Approvals	CCC, EC000030, EN IEC 60947-5-1, INMETRO
Weight	620 g
Wire Size	13 AWG
