SCHMERSAL T4V7H 355-20Z POSITION SWITCH WITH SAFETY FUNCTION 101082481
Zoom
Zoom
Zoom
SCHMERSAL T4V7H 355-20Z POSITION SWITCH WITH SAFETY FUNCTION 101082481
Product Code: 101082481
Technical Specifications
Actuating Element
Roller Lever
Castor Material
Plastic
Lever Material
Metal Film
Maximum Actuating Speed (m/s)
2.5
Maximum Bounce Duration (ms)
2
Maximum Fuse Rating
6 A gG D-fuse
Minimum Ambient Temperature (°C)
-30
No. of Auxiliary Contacts
2
Rated Operational Current AC-15 (A)
4
Rated Operational Current DC-13 (A)
4
Rated Operational Voltage AC-15 (V)
230V AC
Rated Operational Voltage DC-13 (V)
24V DC
Rated Short-circuit Current (A)
1000
Sensor Height (mm)
173.5
Sensor Length (mm)
57.25
Sensor Width (mm)
40.5
Switching Element
NO Contact
Switching Frequency
5000/h
Switching Principle
Slow Action
Termination
Screw Terminals M20 x 1.5
Thermal Test Current (A)
10
Utilisation Category
DC-13
Brand
SCHMERSAL
Connector Type
Female Connector (Side B)
Contact Material
Silver
Degree of Protection
IP67
Enclosure Coating Material
Painted
Housing Material
Light Alloy Die-casting
Maximum Ambient Temperature (°C)
80
Maximum Cable Cross Section (mm²)
2.5
Minimum Cable Cross Section (mm²)
0.75
Minimum Mechanical Life
30000000 Operations
Rated Impulse Withstand Voltage (kV)
6
Rated Insulation Voltage (V)
500
Standards and Approvals
EN ISO 13849-1
