Schmersal 131054782 Position Switch 1NC Die Cast Light Alloy Painted Silver Contact

Product Code: 131054782

Rated for 400 VAC and 4 A
Durable die-cast light alloy housing
IP65 protection against dust and water
Certified by CCC, cULus, ENIEC standards
Silver contacts with slow action switching

Specifications

Standards	EN ISO 13849-1
EAN	8905240000000
eCl@ss Number, Version 9.0	27-27-06-01
ETIM 7.0	EC002593
ETIM 6.0	EC000030
eCl@ss Number, Version 11.0	27-27-26-03
Gross Weight (g)	282
Net Weight (g)	200
Product Type	Position Switch
Brand	SCHMERSAL
Actuating Speed	0.5 m/s
Contact Configuration	1NC
Contact Material	Silver
Degree of Protection	IP65
Housing Material	Die Cast Light Alloy, Painted
Mechanical Life	5000000 Operations
Rated Current	4 A
Rated Voltage	400 VAC
Standards and Approvals	CCC, cULus, EC000030, ENIEC 60947-5-1
Switching Type	Slow Action
Weight	300 g

Documents

IPD Product Catalogue

IPD Product Catalogue V17
