Specifications

No. of Safety Contacts	1
Thermal Test Current (A)	10
Minimum Ambient Temperature (°C)	-30
Termination	Screw Terminals M20 x 1.5
Standards	EN IEC 60947-5-1 / BG-GS-ET-15
Sensor Length (mm)	31
Safety Functions	Yes
Switching Principle	Magnet Snap Action
Switchover Time (ms)	5ms (Maximum)
Switching Frequency	5000/h
No. of Normally-closed Contacts	1
Sensor Width (mm)	30
Sensor Height (mm)	72
Switching Element	Opener (NC)
Maximum Bounce Duration (ms)	3
Actuating Force (N)	6
Contact Opening (mm)	2
Rated Operational Voltage AC-15 (V)	230V AC
Rated Operational Voltage DC-13 (V)	24V DC
Actuating Speed (mm/min)	10
Maximum Cable Cross Section (mm²)	2.5
Rated Insulation Voltage (V)	500
Utilisation Category	DC-13
Maximum Ambient Temperature (°C)	80
Minimum Cable Cross Section (mm²)	0.75
Rated Operational Current AC-15 (A)	4
Rated Operational Current DC-13 (A)	4
Product Type	Position Switch with Safety Function
Brand	SCHMERSAL
Action	Magnet Snap Action
Contact Configuration	NC
Contact Material	Silver
Degree of Protection	IP65
Housing Material	Plastic
Operational Temperature	-30 to 80 deg C
Rated Current	4 A
Rated Frequency	5000/h
Rated Insulation Voltage	500 V
Rated Voltage	230 VAC, 24 VDC
Sensor Size	31 mm L x 30 mm W x 72 mm H
Standards and Approvals	BG-GS-ET-15, EN IEC 60947-5-1
