Schmersal 101174995 Position Switch with Safety Function Roller Lever 1NO-1NC Metal Die Cast Zinc Silver Contact

Product Code: 101174995

  • Rated for 230 VAC, 4 A
  • Durable die-cast zinc housing
  • Snap action roller lever actuator
  • Long mechanical life of 20 million ops
  • Complies with multiple standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Maximum Temperature (°C) 80
Minimum Temperature (°C) -30
Product Type Position Switch with Safety Function
Brand SCHMERSAL
Series 255
Actuating Speed 240 mm/min
Actuator Type Roller Lever
Cable Cross Section 0.75 sq-mm
Contact Configuration 1NO+1NC
Contact Material Silver
Degree of Protection IP67
Housing Material Metal, Die Cast Zinc
Mechanical Life 20000000 Operations
Number of Auxiliary Contacts 1
Rated Current 4 A
Rated Voltage 230 VAC
Standards and Approvals BG-GS-ET-15, CCC, cULus, EC000030, ENIEC 60947-5-1, ENISO 13849-1
Switching Type Snap Action
Weight 238 g

Description

Explore the Schmersal 255 Series Position Switch, a robust machine safety solution featuring a durable metal enclosure. This switch is equipped with a roller lever actuating element and offers both NO and NC contact switching elements. It's designed to handle a thermal test current of 10 A and is rated for utilisation categories AC-15 at 230 VAC, 4 A, as well as DC-13 at 24 VDC, 1 A. Ideal for engineers seeking reliable performance in demanding industrial environments.
