Novaris SSP1-32-50-275 Surge Protector 15kA 1-P 1 PH 32A 50kA 230VAC TS35 Panel Mount Metal IP20

Product Code: SSP1-32-50-275

  • Surge protection with 230 VAC, 32 A rating
  • Quick response time: <5 ns (L-N), <100 ns (N-PE)
  • LED status display for easy monitoring
  • Compact design: 54x69x95 mm, metal build
  • Complies with IEC, AS/NZS, UL standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Lightning Impulse Current (10/350 &#181;s) - Iimp (kA) 6.25 (L-N), 15 (N-PE)
Maximum Continuous Operating Voltage MCOV AC (V) 275 (L-N), 255 (N-PE)
Maximum Discharge Current (8/20µs) - Imax (kA) 50 (L-N) 60 (N-PE)
No. of Poles 1P+N+PE
Nominal Discharge Current (8/20µs) - In (kA) 20 (L-N), 50 (N-PE)
No. of Phases 1
Nominal Voltage AC (V) 230
Operational Temperature Range (&#176;C) -40 to 70
Dimensions (mm) 95H x 54W x 69D
Voltage Protection Level - Up (kV) <1.3 (L-N)
Maximum Load Current - I? (A) 32
Product Type Surge Protector
Brand NOVARIS
Series SSP1
Connection Type Series
Degree of Protection IP20
Depth 95 mm
Discharge Current 50 kA
Display Type LED Status
Fuse Rating 32 A
Height 69 mm
Humidity 5-95%
Interrupt Rating 100 A
Lightning Impulse Current 15 kA
Material Metal
Modes of Protection L-N, L-PE, N-PE
Mounting Type TS35 DIN Rail, Panel
Number of Poles 1
Operational Temperature -40 to 70 deg C
Phase 1
Rated Current 32 A
Rated Short Circuit Current 25 kA
Rated Voltage 230 VAC
Response Time <5 ns (L-N), <100 ns (N-PE)
Standards and Approvals IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 3rd Edition, IEEE 62.41.2:2002
Voltage Protection Level <800 V
Weight 315 g
Width 54 mm

Description

The Series Surge Protector is a single-phase device with 1P+N+PE configuration. It operates at a nominal voltage of 230 VAC and has a maximum continuous operating voltage of 275VAC. It offers excellent protection against surges, with a maximum discharge current of 50kA (L-N) and 60kA (N-PE) at 8/20ms. The nominal discharge current is 20kA (L-N) and 50kA (N-PE) at 8/20us. With a maximum load current of 32A, this surge protector provides reliable protection for your electrical equipment. It has a voltage protection level of less than 1300V (L-N) when the nominal discharge current is applied. The Series Surge Protector features series connection and all mode protection, ensuring comprehensive coverage against surges. It also comes with LED status indicators per phase for easy monitoring. Designed for convenience, this surge protector can be easily mounted on DIN rails.
