Novaris SSP1-63-100-275 Surge Protector 6.25kA 15kA 1 PH 63A 100kA 230VAC TS35 Panel Mount Metal IP20

Product Code: SSP1-63-100-275

  • Surge protection for 230 VAC systems
  • Handles up to 63 A current
  • LED status display for easy monitoring
  • Compact size: 54x69x95 mm, fits TS35 DIN rail
  • Complies with IEC and AS/NZS standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Lightning Impulse Current (10/350 µs) - Iimp (kA) 12.5 (L-N), 15 (N-PE)
Maximum Continuous Operating Voltage MCOV AC (V) 275 (L-N), 255 (N-PE)
Maximum Discharge Current (8/20µs) - Imax (kA) 100 (L-N) 60 (N-PE)
No. of Poles 1P+N+PE
Nominal Discharge Current (8/20µs) - In (kA) 40 (L-N), 50 (N-PE)
No. of Phases 1
Nominal Voltage AC (V) 230
Operational Temperature Range (°C) -40 to 70
Dimensions (mm) 72W x 69H x 95L
Voltage Protection Level - Up (kV) <1.7 (L-N)
Maximum Load Current - I? (A) 63
Weight (g) 445
Product Type Surge Protector
Brand NOVARIS
Series SSP1
Connection Type Series
Degree of Protection IP20
Depth 95 mm
Discharge Current 100 kA
Display Type LED Status
Fuse Rating 63 A
Height 69 mm
Humidity 5-95%
Interrupt Rating 100 A
Lightning Impulse Current 6.25 kA (L-N), 15 kA (N-PE)
Material Metal
Modes of Protection L-N, L-PE, N-PE
Mounting Type TS35 DIN Rail, Panel
Operational Temperature -40 to 70 deg C
Phase 1
Rated Current 63 A
Rated Short Circuit Current 25 kA
Rated Voltage 230 VAC
Response Time <5 ns (L-N), <100 ns (N-PE)
Standards and Approvals IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 3rd Edition, IEEE 62.41.2:2002
Voltage Protection Level <800 V
Weight 415 g
Width 54 mm

Description

The Novaris SSP1 range of surge protectors are designed to provide comprehensive protection to AC power circuits. With a two-port series configuration, they handle load currents up to 63A. Suitable for various AC supply systems, they offer all-mode protection and are housed in a safe metal enclosure.
