Novaris SSP1-63-50-275-A Surge Protector 15kA 1 PH 63A 230VAC TS35 Panel Mounting Metal IP20

Product Code: SSP1-63-50-275-A

  • Surge protection for 230 VAC systems
  • Fast response time under 5 ns (L-N)
  • LED status display for easy monitoring
  • Mounts on TS35 DIN rail or panel
  • Complies with IEC, AS/NZS, UL standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Lightning Impulse Current (10/350 µs) - Iimp (kA) 6.25 (L-N), 15 (N-PE)
Maximum Continuous Operating Voltage MCOV AC (V) 275 (L-N), 255 (N-PE)
Maximum Discharge Current (8/20µs) - Imax (kA) 50 (L-N) 60 (N-PE)
No. of Poles 1P+N+PE
Nominal Discharge Current (8/20µs) - In (kA) 20 (L-N), 50 (N-PE)
No. of Phases 1
Nominal Voltage AC (V) 230
Operational Temperature Range (°C) -40 to 70
Dimensions (mm) 72W x 69H x 95L
Voltage Protection Level - Up (kV) <1.3 (L-N)
Maximum Load Current - I? (A) 63
Alarm Contact Yes
Weight (g) 420
Product Type Surge Protector
Brand NOVARIS
Series SSP1
Connection Type Series
Degree of Protection IP20
Depth 95 mm
Display Type LED Status
Fuse Rating 63 A
Height 69 mm
Humidity 5-95%
Interrupt Rating 100 A
Lightning Impulse Current 15 kA
Material Metal
Modes of Protection L-N, L-PE, N-PE
Mounting Type TS35 DIN Rail, Panel
Operational Temperature -40 to 70 deg C
Phase 1
Rated Current 63 A
Rated Short Circuit Current 25 kA
Rated Voltage 230 VAC
Response Time <5 ns (L-N), <100 ns (N-PE)
Standards and Approvals IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 3rd Edition, IEEE 62.41.2:2002
Voltage Protection Level <800 V
Weight 395 g
Width 72 mm

Description

The Series Surge Protector is a single-phase device designed for 1P+N+PE systems. It operates at a nominal voltage of 230 VAC and can handle a maximum continuous operating voltage of 275VAC. In terms of protection, it has a maximum discharge current of 50kA (L-N) and 60kA (N-PE) at 8/20ms, as well as a nominal discharge current of 20kA (L-N) and 50kA (N-PE) at 8/20us. The maximum load current it can handle is 63A. For voltage protection, it offers a voltage protection level of less than 1300V (L-N) when the nominal discharge current is applied. It features series connection Active alarm and All mode protection. Additionally, this surge protector comes with LED status indicators per phase and can be conveniently mounted on DIN rails.
