Specifications

Operational Temperature Range (°C)	-40 to 70
Response Time (ns)	5
Enclosure Material	Polycarbonate
No. of Lines	1 Pair
Product Type	Surge Protector
Brand	NOVARIS
Connection Type	Series
Degree of Protection	IP20
Depth	71 mm
Discharge Current	3.6 kA
Height	110 mm
Humidity	5 to 95%
Modes of Protection	Transverse and Common Modes
Mounting Type	TS35 DIN Rail
Number of Lines	1 pair
Rated Current	1.8 kA
Rated Voltage	380 VDC
Resistance	0.02 Ohm
Voltage Protection Level	<800 V
Width	7 mm
