When it comes to safeguarding your electrical systems, choosing the right Surge Protection Device (SPD) is crucial. This SPD is designed for industrial and commercial applications, offering robust protection against voltage spikes and surges.
Rated for a voltage of 120/240 V and a current capacity of 15 kA, this device ensures reliable performance under demanding conditions. It features an IP20 degree of protection, making it suitable for indoor environments where dust ingress may be a concern but not moisture.
Designed for ease of installation, this SPD mounts on a standard 35 mm DIN rail. Its compact dimensions—54 mm in width, 90 mm in height, and 66 mm in depth—allow it to fit comfortably within most electrical panels without occupying excessive space.
Operating efficiently across a wide temperature range from -40 to 80 degrees Celsius, this device is built to withstand extreme environmental conditions. The thermoplastic construction adds durability while keeping the weight manageable at just 299 g.
In terms of safety standards and approvals, this SPD meets KEMA and UL certifications, ensuring compliance with international safety norms. The response time is impressively fast at <=25 ns, providing quick action against transient over-voltages.
The device features three poles and an interrupt rating of 125 A. It accommodates various conductor types with cross-sections ranging from 1.5 sq-mm solid/flexible up to 35 sq-mm stranded or 25 sq-mm flexible conductors.
With a voltage protection level capped at <=0.7 kV and a rated short circuit current capacity of up to 50 kA, this Type 2/Class II SPD provides substantial defense against electrical disturbances that can damage sensitive equipment.
Overall, this surge protection solution combines reliability with efficient design principles tailored for technical professionals seeking dependable performance in their power distribution systems.
