Specifications

Cable Cross Section (mm²)	0.2
Cable Length (m)	2
Dimensions (mm)	20W x 80H x 52D
Pollution Degree	3 (Industrial environment)
Rated Supply Voltage DC (V)	12 to 24
Enclosure Material	ABS
Outputs	Relay Contact 1A
Storage Temperature (°C)	-20 to +70
Current Consumption (mA)	<50 (unit), <135 (include sensor)
Output Operation	Output Relay = ON when Input signal from sensor = ON
Mounting Method	Bracket (MS-DIN-3)
Net Weight (g)	85
Ambient Temperature (°C)	-10 to +60
Response Time (ms)	<5
To Suit	EX-F71/F72, EX-F61/F62 leak detection sensors
Product Type	Leak Detection Sensor
Brand	PANASONIC
Cable Length	2 m
Cable Type	4 core cabtyre
Connection Type	SL-CP1
Connector Type	SL-CP1
Housing Material	ABS
Humidity	35-85%
Mounting Type	MS-DIN-3 Bracket
Operation Indicator	Orange LED ON
Operational Temperature	-20 to 70 deg C
Output Type	1 A Relay
Rated Current	<50 mA, <135 mA
Rated Voltage	12-24 VDC
Relative Humidity	35 to 85%
Response Time	<5 ms
Utilisation Category	DC-12 or DC-13
Weight	85 g
