Specifications

Dimensions (mm)	72W x 70H x 95D
Nominal Voltage AC (V)	400
Response Time (ns)	<5
Enclosure Material	Aluminium
Backup fuse rating (A)	63
Maximum Temperature (°C)	70
Minimum Temperature (°C)	-40
Weight (g)	550
Mounting Method	TS35 DIN Rail
Minimum Relative Humidity	5%
Operating Humidity	95%
Maximum Discharge Current (8/20µs) (kA)	100
Earth Leakage Current (A)	<10
Short Circuit Withstand Level (kA)	50
Product Type	Surge Protection
Brand	NOVARIS
Connection Type	Shunt
Degree of Protection	IP20
Depth	95 mm
Display Type	LED Power and Thermal Failure
Enclosure Coating Material	Black powdercoat
Fuse Rating	63 A
Height	70 mm
Humidity	5-95%
Lightning Impulse Current	12.5 kA
Material	Aluminium
Modes of Protection	L-L, L-PE
Mounting Type	TS35 DIN Rail
Number of Ports	1
Operational Temperature	-40 to 70 deg C
Phase	3
Rated Current	100 kA (L-PE)
Rated Short Circuit Current	50 kA
Rated Voltage	400 VAC
Response Time	<5 ns (L-PE)
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007, IEEE 62.41.2:2002, UL 1449 3rd Edition
Tightening Torque	2 N-m
Voltage Protection Level	<800 V
Weight	550 g
Width	72 mm
