Specifications

Dimensions (mm)	72W x 70H x 95D
Nominal Discharge Current (8/20µs) - In (kA)	40
Nominal Voltage AC/DC (V)	220
No. of Phases	2
Operational Temperature Range (°C)	-40 to 70
Voltage Protection Level - Up (kV)	1.2
Response Time (ns)	5
Enclosure Material	Aluminium
Backup fuse rating (A)	63
Weight (g)	300
Maximum Continuous Voltage AC (V)	320
Maximum Discharge Current (8/20µs) (kA)	100
Product Type	Surge Protection
Brand	NOVARIS
Connection Type	Shunt
Degree of Protection	IP20
Depth	95 mm
Display Type	LED Power and Thermal Failure
Fuse Rating	32 A
Height	70 mm
Humidity	5-95%
Lightning Impulse Current	4 kA (L-PE)
Material	Aluminium
Modes of Protection	L-L, L-PE
Mounting Type	TS35 DIN Rail
Number of Ports	1
Operational Temperature	-40 to 70 deg C
Phase	3
Rated Current	50 kA (L-PE)
Rated Short Circuit Current	25 kA
Rated Voltage	220 VAC
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007, IEEE 62.41.2:2002, UL 1449 3rd Edition
Tightening Torque	2 N-m
Voltage Protection Level	<1300 V
Weight	320 g
Width	54 mm
