Specifications

Dimensions (mm)	54W x 70H x 95D
No. of Phases	3
Nominal Voltage AC (V)	220
Response Time (ns)	<5
Enclosure Material	Aluminium
Maximum Temperature (°C)	70
Minimum Temperature (°C)	-40
Weight (g)	320
Mounting Method	TS35 DIN Rail
Minimum Relative Humidity	5%
Operating Humidity	95%
Maximum Discharge Current (8/20µs) (kA)	50
Product Type	Surge Protection
Brand	NOVARIS
Connection Type	Shunt
Degree of Protection	IP20
Depth	95 mm
Display Type	LED Power and Thermal Failure
Enclosure Coating Material	Black powdercoat
Fuse Rating	32 A
Height	70 mm
Humidity	5-95%
Lightning Impulse Current	4 kA (L-PE)
Material	Aluminium
Modes of Protection	L-L, L-PE
Mounting Type	TS35 DIN Rail
Number of Ports	1
Operational Temperature	-40 to 70 deg C
Phase	3
Rated Current	50 kA (L-PE)
Rated Short Circuit Current	25 kA
Rated Voltage	220 VAC
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007, IEEE 62.41.2:2002, UL 1449 3rd Edition
Tightening Torque	2 N-m
Voltage Protection Level	<1300 V
Weight	320 g
Width	54 mm
