Specifications

Nominal Discharge Current (8/20µs) - In (kA)	100
No. of Phases	3
Operational Temperature Range (°C)	-40 to 70
Enclosure Material	Aluminium
Maximum Continuous Voltage AC (V)	275
Product Type	Surge Diverter
Brand	NOVARIS
Connection Type	Shunt
Contact Configuration	SPDT
Degree of Protection	IP20
Depth	200 mm
Display Type	Digital
Fuse Rating	63 A
Height	80 mm
Humidity	5-95%
Lightning Impulse Current	12.5 kA
Material	Metal
Modes of Protection	L-L, L-N
Mounting Type	Panel
Number of Ports	1
Operational Temperature	-40 to 70 deg C
Phase	3
Rated Current	100 kA (L-N)
Rated Short Circuit Current	50 kA
Rated Voltage	230 VAC
Response Time	<25 ns (L-N)
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007, UL 1449 3rd Edition, IEEE 62.41.2:2002
Tightening Torque	0.5 N-m, 2 N-m
Voltage Protection Level	<800 V
Weight	2.68 kg
Width	200 mm
