Specifications

No. of Phases	3
Operational Temperature Range (°C)	-40 to 70
Response Time (ns)	Instantaneous
Maximum Load Current - I? (A)	1200
Maximum Continuous Voltage AC (V)	275
Maximum Discharge Current (8/20µs) (kA)	200
Product Type	Surge Filter
Brand	NOVARIS
Connection Type	Series
Contact Configuration	SPDT
Degree of Protection	IP55
Depth	340 mm
Display Type	7-Segment LED, Percentage Active
Height	700 mm
Humidity	5 to 95%
Modes of Protection	L-N, L-PE, N-PE
Mounting Type	Wall
Operational Temperature	-40 to 70 deg C
Phase	3
Rated Current	200 kA
Rated Frequency	50 Hz
Rated Short Circuit Current	1200 A
Rated Voltage	230 VAC
Standards and Approvals	IEC 61643-11 Class I, II, III, AS/NZS 1768 Category C, B, A, IEEE C62.41 Category C, B, A, UL1449 Fourth Edition
Tightening Torque	0.5 N-m
Voltage Protection Level	<360 V
Weight	120 g
Width	1300 mm
