Specifications

No. of Phases	3
Operational Temperature Range (°C)	-40 to 70
Response Time (ns)	Instantaneous
Maximum Load Current - I? (A)	160
Maximum Continuous Voltage AC (V)	275
Maximum Discharge Current (8/20µs) (kA)	200
Product Type	Surge Filter
Brand	NOVARIS
Connection Type	Series
Degree of Protection	IP20
Depth	198 mm
Fuse Rating	160 A
Height	530 mm
Humidity	5-95%
Lightning Impulse Current	25 kA (L-N)
Modes of Protection	L-N, L-PE, N-PE
Mounting Type	Panel
Number of Ports	2
Operational Temperature	-40 to 70 deg C
Phase	3
Rated Current	200 kA (L-N)
Rated Short Circuit Current	50 kA
Rated Voltage	230 VAC
Standards and Approvals	IEC 61643-11, AS/NZS 1768
Tightening Torque	0.5 N-m
Voltage Protection Level	<2.65 kA (L-N)
Weight	45 g
Width	544 mm
