Novaris TSC1-DIN Transient Surge Counter 100A 200kA TS35 DIN Rail Mount Metal IP20

Product Code: TSC1-DIN

  • Resettable LCD display for easy reading
  • Handles up to 100 A, 200 kA current
  • IP20 protection for indoor use
  • Mounts on TS35 DIN rail
  • Operates from -40 to 70°C
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Operational Temperature Range (°C) -40 to 70
Maximum Discharge Current (8/20µs) (kA) 200
Sensitivity 85A
Product Type Transient Surge Counter
Brand NOVARIS
Degree of Protection IP20
Display Type Resettable, LCD
Humidity 5-95%
Material Metal
Mounting Type TS35 DIN Rail
Operational Temperature -40 to 70 deg C
Rated Current 100 A, 200 kA
Standards and Approvals IEC 62561-6:2011
Weight 600 g

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
