ABB 1SDA068201R1 Fixed Part Withdrawable Circuit-Breaker 3-P 690/500VAC/DC 160A Rear Flat Horizontal For: XT2

Product Code: 1SDA068201R1

  • Supports up to 160 A current
  • Withstands impulse voltage of 8 kV
  • Insulation voltage rated at 1000 V
  • Compatible with XT2 devices
  • Meets IEC60947-2 standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Poles 3
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) 1000
Suitable For XT2
EAN 8015644696313
Poles 3P
Main Circuit Electrical Connection Bolt Connection
Product Type Fixed Part Withdrawable Circuit-Breaker
Brand ABB
Number of Poles 3
Rated Current 160 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 8 kV
Rated Insulation Voltage 1000 V
Rated Voltage 690/500 VAC/VDC
Standards and Approvals IEC60947-2
Suitable For Use With XT2
Weight 1.44 kg

Description

FIXED PART WITHDRAWABLE FOR C.BREAKER TMAX THREE-POLE WITH REAR TERMINALS HORIZONTAL XT2
