IDEC YW1P-2UQ3R Unibody Pilot Light LED Red 12VDC 22mm Dia Mount Hole

Product Code: YW1P-2UQ3R

  • Operates at 24 VDC
  • IP65 protection rating
  • LED lamp in pure white
  • Fits 22 mm mounting holes
  • Insulation resistance of 100 MOhm
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 29.8W x 29.8H x 57.5D
Operating Voltage DC (V) 12
Operating Voltage AC (V) 12
Product Type Unibody Pilot Light
Brand IDEC
Series YW
Colour Red
Degree of Protection IP65
Insulation Resistance 100 MOhm
Lamp Colour Pure White
Lamp Type LED
Model Dome Full Voltage - LED Lamp
Mounting Hole Diameter 22 mm
Operational Temperature -20 to 55 deg C
Rated Voltage 24 VDC

Description

The IDEC YW1P-2UQ3R is a unibody pilot light designed for efficient use of space with its 10mm thick contact blocks. It features a removable operator for flexibility and ease of maintenance. The compact, lightweight design includes a durable metal bezel. Installation and removal are simplified thanks to the separate contact block. Additionally, the pilot light offers enhanced visibility with a large lens that provides a wide viewing angle, suitable for various industrial applications.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
