IDEC CPU 24V DC TRANS. SINK,MICRO SMART PLC FC6A-C24K1CE

Product Code: FC6A-C24K1CE

The IDEC FC6A-C24K1CE is a versatile MicroSmart PLC designed for complex automation tasks. It features 16 I/O points with transistor source output and operates on 12VDC. This unit supports Modbus TCP and RTU protocols and offers an embedded SD memory port for enhanced data storage. Users can select between RS232C and RS485 interfaces, allowing for flexible connectivity options. The PLC can be expanded with up to three additional modules, boasts data logging capabilities, web server functions, and substantial programming and data memory space. It meets cULus CE Class 1 Div 4 standards, ensuring safe operation in demanding industrial environments.

Technical Specifications

Brand IDEC
Programming Language Ladder, Script
Warranty Period (Months) 36
Operational Temperature Range (°C) -25 to 65
No. of Ethernet Ports 1
No. of Inputs 14
No. of Outputs 10
Operating Voltage DC (V) 24
Power Consumption (W) 4.8
Rated Frequency (Hz) 50/60
Cable Length (m) 100
Dimensions (mm) 106.5W x 110H x 75.7D
Timer Function 1024
Weight (g) 380
Voltage Range (DC) 20.4 to 28.8
Voltage Range AC (V) 85 to 264
