Schmersal 101163556 Front Element Pushbutton Roller Lever

Product Code: 101163556

  • High protection: IP67, IP69K rated
  • Durable: 1 million operations lifespan
  • Wide temp range: -25 to 80°C
  • Strong build: Shock resistant up to 30 g/ms
  • Versatile mounting with flange design
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Front Element Pushbutton
Brand SCHMERSAL
Actuating Torque 0.15 N-m
Actuator Type Roller Lever
Ambient Temperature -25 to 80 deg C
Bezel Colour Green, Silver
Bezel Material ABS
Colour Green (Operating Element), Silver (Front Ring ), White (Bellows)
Degree of Protection IP67, IP69K
Diameter 44.5 mm
Material ABS (Operator)
Mechanical Life 1 million Operations
Mounting Type Flange
Shock Resistance 30 g/ms
Standards and Approvals BG, CCC, cULus, EN IEC 60204-1, EN IEC 60947-1, EN IEC 60947-5-1/-5-3/-5-5, EN IEC 62061, IPA
Tightening Torque 0.6 N-m
Vibration Resistance 20 g

Description

<p>When selecting a pushbutton for industrial and commercial applications, it&amp;#39;s crucial to consider durability, compliance with standards, and suitability for specific environments. This particular pushbutton offers a robust set of features designed to meet the demanding requirements of such settings.</p><p>With an impressive degree of protection rated at IP67 and IP69K, this pushbutton is engineered to withstand harsh conditions including dust ingress and high-pressure water jets. This makes it an ideal choice for environments where reliability in extreme conditions is non-negotiable.</p><p>The design incorporates a roller lever actuator type, providing ease of use and efficient operation. It requires an actuating torque of 0.15 N-m, ensuring that activation is smooth yet deliberate. The bezel material is made from durable ABS, available in green or silver colors, offering both aesthetic flexibility and resilience against wear.</p><p>For mounting purposes, this pushbutton utilizes a flange type installation method which ensures secure attachment within your system setup. The device has been tested for vibration resistance up to 20 g and shock resistance up to 30 g/ms, guaranteeing stable performance even under dynamic conditions.</p><p>In terms of longevity, the mechanical life expectancy stands at an impressive one million operations. This underscores its capability to deliver consistent performance over extended periods without frequent replacements or maintenance interruptions.</p><p>Operating temperatures range from -25&amp;#176;C to 80&amp;#176;C, making it suitable for diverse climate conditions typical in various industrial settings across Australia.</p><p>Moreover, this product complies with numerous international standards including BG, CCC, cULus as well as several EN IEC specifications like 60204-1 and 60947 series among others. These certifications affirm its safety credentials and operational reliability across different systems worldwide.</p><p>Overall tightening torque required during installation is measured at 0.6 N-m ensuring secure assembly while maintaining operational integrity throughout its use lifecycle.</p><p>This combination of features positions the pushbutton as a reliable component tailored for those seeking efficiency coupled with uncompromising quality assurance in their technical solutions arsenal.</p>
