Specifications

Poles	2P
Breaking Capacity (kA)	15 @400 V AC
Current Rating (A)	40
Family	S200MUC
AC Voltage (V)	400/415
DC Voltage (V)	440
Icn-Rated Short Circuit Capacity (kA)	10
Inc-Rated Conditional Short Circuit Capacity (kA)	15
Impulse Withstand Voltage (kV/1.2µS)	4
Product Type	Miniature Circuit breaker
Brand	ABB
Ambient Temperature	-25 to 55 deg C Operation, -40 to 70 deg C Storage
Application	Industrial
Breaking Capacity	15 kA at 400 VAC
Collection	S200MUC
Curve Type	K
Degree of Pollution	IP3
Degree of Protection	IP20
Depth	69 mm
Height	88 mm
Housing Colour	RAL 7035 Grey
Impulse Voltage	4 kV
Number of Poles	2
Power Loss	7.52 W
Rated Current	40 A
Rated Frequency	50/60 Hz
Rated Voltage	400/415 VAC
Short Circuit Capacity	10 kA
Standards and Approvals	CSA 22.2 No. 235, IEC/EN 60947-2, UL 1077
Terminal Type	Screw Clamp
Tightening Torque	2.8 N-m
Trip Curve	K Curve
Width	35 mm
