NOVARIS DIN MOUNT SURGE FILTER, 32A LOAD, 275VAC SFD1-32-50-275

Product Code: SFD1-32-50-275

The Novaris SFD1-32-50-275 is a compact, all-metal enclosed DIN mount single phase surge filter designed to protect sensitive loads in space restricted applications. It offers three stages of protection and complies with multiple standards.

Technical Specifications

Brand NOVARIS
Series SFD1
Lightning Impulse Current (10/350 µs) - Iimp (kA) 6.25 (L-N) 15 (N-PE)
Mounting Type DIN rail
Operational Temperature Range (°C) -40 to 70
Maximum Continuous Operating Voltage MCOV AC (V) 275 (L-N), 255 (N-PE)
Maximum Discharge Current (8/20µs) - Imax (kA) 50 (L-N), 60 (N-PE)
Maximum Load Current - I? (A) 32
No. of Phases 1
No. of Poles 1P+N+PE
Nominal Discharge Current (8/20µs) - In (kA) 20 (L-N), 50 (N-PE)
Nominal Voltage AC (V) 230
Dimensions (mm) 108W x 69H x 95L
Weight (g) 760
Voltage Protection Level - Up (kV) < 1 (L-N), <1.5 (N-PE)
Degree of Protection IP20
Standards and Approvals IEC 61643-11, AS/NZS 1768, UL 1449, IEEE 62.41.2
