Mersen OTM15 Fast-Acting Midget Fuse 15A 250VAC 0.41 in Dia 1.5 in L 10kA Interrupt Ferrule

Product Code: OTM15

  • Rated for 15A current and 250VAC voltage
  • Compact size: 1.5 in length, 0.41 in diameter
  • High interrupt rating of 10 kA
  • Tin plated copper terminals for reliable connection
  • Paper body and insulation materials
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Body Size (mm) 10 x 38
Functionality Fast Acting
Rated Current (A) 15
Rated Voltage AC (V) 250
Interrupting Rating AC (kA) 10
Product Type Fast-Acting Midget Fuse
Brand MERSEN
Body Material Paper
Body Style Ferrule
Connection/Terminal Material Tin Plated Copper
Diameter 0.41 in
Insulation Material Paper
Interrupt Rating 10 kA
Length 1.5 in
Mounting Type Clip
Rated Current 15 A
Rated Frequency 50/60 Hz
Rated Voltage 250 VAC
Terminal Type Ferrule
Weight 0.012 lb

Description

OTM midget fast-acting ferrule type fuses offer affordable protection for general purpose lighting, heating, and control circuits. They have a voltage rating of 250VAC and a rated current of 15A. These fuses can interrupt short circuit currents up to 10kA. They are UL Listed to standard 248-14.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
