Mersen OT250 Fast-Acting General Purpose Fuse 250A 250VAC/DC Class K5 2.06 in Dia x 8.63 in L Blade Terminal

Product Code: OT250

  • Rated for 250A and 250VAC/VDC
  • High breaking capacity of 50kA
  • Compact size: 2.06in Dia x 8.63in L
  • Blade terminals with tin-plated copper
  • Durable poly tube insulation
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Body Size (mm) 53 x 123
Functionality General Purpose
Rated Current (A) 250
Rated Voltage AC/DC (V) 250
Interrupting Rating AC (kA) 50
Interrupting Rating DC (kA) 20
Product Type Fast-Acting General Purpose Fuse
Brand MERSEN
Body Material Poly Tube
Body Size 2.06 in Dia x 8.63 in L
Body Style Blade
Breaking Capacity 50 kA
Connection/Terminal Material Tin Plated Copper
Fuse Class Class K5
Insulation Material PolyTube
Mounting Type Clip
Rated Current 250 A
Rated Frequency 50/60 Hz
Rated Voltage 250 VAC/VDC
Terminal Type Blade
Weight 1.45 lb

Description

The One-Time OT general purpose fuses offer affordable protection for feeder and branch-circuits that serve lighting, heating, and other non-motor loads. These fuses have a voltage rating of 250V AC/DC and a rated current of 250A. They are capable of safely interrupting short circuit currents up to 50kA/AC and 20kA/DC in all ratings.
