Mersen OT450 Fast-Acting General Purpose Fuse 450A 250VAC/DC Class K5 2.56 in Dia x 10.38 in L Blade Terminal

Product Code: OT450

  • Rated for 450 A, 250 VAC/VDC
  • High breaking capacity of 50 kA
  • Compact size: 2.56 in Dia x 10.38 in L
  • Blade terminal with tin-plated copper
  • Durable poly tube body and insulation
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Body Size (mm) 66 x 150
Functionality General Purpose
Rated Current (A) 450
Rated Voltage AC/DC (V) 250
Interrupting Rating AC (kA) 50
Interrupting Rating DC (kA) 20
Product Type Fast-Acting General Purpose Fuse
Brand MERSEN
Body Material Poly Tube
Body Size 2.56 in Dia x 10.38 in L
Body Style Blade
Breaking Capacity 50 kA
Connection/Terminal Material Tin Plated Copper
Fuse Class Class K5
Insulation Material PolyTube
Mounting Type Clip
Rated Current 450 A
Rated Frequency 50/60 Hz
Rated Voltage 250 VAC/VDC
Terminal Type Blade
Weight 2.158 lb

Description

The One-Time OT general purpose fuses offer affordable protection for feeder and branch-circuits that supply lighting, heating, and other non-motor loads. These fuses have a voltage rating of 250V AC/DC and a rated current of 450A. They are capable of safely interrupting short circuit currents up to 50kA/AC and 20kA/DC in all ratings.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
