Mersen AJT500 Power Fuse 500A 600/500VAC/DC Class J 63.5mm Dia x 203.2mm L Blade Terminal Class J 200kA

Product Code: AJT500

  • 500 A current rating for robust performance
  • 600/500 VAC/VDC voltage capacity
  • High breaking capacity of 200 kA
  • Compact size: 63.5 mm dia x 203.2 mm length
  • Versatile mounting: Clip or bolted options
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Body Size (mm) 64 x 95
Functionality Time Delay
Rated Current (A) 500
Rated Voltage DC (V) 500
Rated Voltage AC (V) 600
Interrupting Rating AC (kA) 200
Interrupting Rating DC (kA) 100
Product Type Time Delay Power Fuse
Brand MERSEN
Body Material GMG
Body Size 63.5 mm Dia x 203.2 mm L
Body Style Bolted Tag
Breaking Capacity 200 kA
Connection/Terminal Material Brass
Fuse Class Class J
Insulation Material GMG
Mounting Type Clip, Bolted
Rated Current 500 A
Rated Frequency 50/60 Hz
Rated Voltage 600/500 VAC/VDC
Terminal Type Blade
Weight 1.3698 kg

Description

AJT Time delay Class 'J' ferrule type fuses are designed to handle typical motor and transformer inrush currents. They have time-delay characteristics and provide superior current-limiting ability. These fuses have a voltage rating of 600VAC/500VDC and a rated current of 500A.
