When selecting the right fuse for your industrial or commercial application, understanding the specifications and features is crucial. This UL North American Class J fuse offers a robust solution designed to meet demanding electrical distribution needs.
With a rated current of 225 A, this fuse is suitable for applications requiring significant power handling. It supports both AC and DC systems with a rated voltage of 600/300 VAC/VDC, providing versatility across various setups. Its substantial breaking capacity of 200 kA ensures it can handle high fault conditions effectively, minimizing risks in critical environments.
The fuse's body measures at 2.12 inches in diameter and extends to a length of 7.13 inches, making it compact enough for streamlined integration into existing systems while maintaining its durability. Weighing just 1.75 pounds, it strikes an optimal balance between size and performance.
Designed with practicality in mind, the mounting type is clip-based, facilitating straightforward installation and replacement processes that save time during maintenance routines. The blade terminal type further enhances connectivity reliability by ensuring secure connections.
Constructed from GMG material for both the body and insulation, this fuse exhibits excellent thermal resistance properties essential for maintaining stability under load variations. Additionally, the brass alloy used in its connection/terminal material contributes to superior conductivity and corrosion resistance—key factors that extend operational lifespan even in harsh conditions.
Operating within a frequency range of 50/60 Hz allows compatibility with most global power systems without compromising efficiency or safety standards.
In summary, this Class J fuse combines high performance with reliable safety features tailored to meet rigorous industrial demands—a testament to quality engineering suited for professionals seeking dependable protection solutions.
