Mersen A4J70 Power Fuse 70A 600/300VAC/DC Class J 1.06 in Dia x 4.63 in L 200kA Fast Acting

Product Code: A4J70

  • Rated current of 70 A
  • Voltage up to 600/300 VAC/VDC
  • High breaking capacity of 200 kA
  • Blade terminal with silver-plated copper
  • Compact size: 1.06 in Dia x 4.63 in L
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Rated Current (A) 70
Rated Voltage DC (V) 300
Rated Voltage AC (V) 600
Body Size (mm) 29 x 67
Functionality Fast Acting
Interrupting Rating AC (kA) 200
Interrupting Rating DC (kA) 100
Product Type Power Fuse
Brand MERSEN
Body Material GMG
Body Size 1.06 in Dia x 4.63 in L
Body Style Bolted Tag
Breaking Capacity 200 kA
Connection/Terminal Material Silver Plated Copper
Fuse Class Class J
Insulation Material GMG
Mounting Type Clip
Rated Current 70 A
Rated Frequency 50/60 Hz
Rated Voltage 600/300 VAC/VDC
Terminal Type Blade
Weight 0.24 lb

Description

The A4J Fast-acting Class 'J' ferrule type fuses provide exceptional current-limiting protection for various applications such as capacitors, load centers, panelboards, switchboards, busducts, feeder circuits, circuit breakers, lighting, heating, and general loads. These fuses have a voltage rating of 600VAC/300VDC and a rated current of 70A.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
