ABB S202C-C6 Miniature Circuit Breaker 10kA at 415VAC 2-P 6A 400/415VAC C-Curve

Product Code: S202C-C6

  • 6 A MCB with dual poles for efficient protection
  • High 10 kA breaking capacity at 415 VAC
  • Compact size: 18 mm width, fits standard setups
  • Operates in wide temp range: -25 to 55°C
  • Complies with IEC/EN 60898-1 standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Poles 2P
Operational Temperature Range (°C) -25 to +55
Rated Current (A) 6
Rated Frequency (Hz) 50/60
Rated Impulse Withstand Voltage (kV) 4
Rated Operational Voltage AC (V) 415
Breaking Capacity 415V AC - Icu (kA) 10
Dimensions (mm) 18Wx86Hx70D
Poles 2P
Breaking Capacity (kA) 10 @415 V AC
Current Rating (A) 6
Family S202C
AC Voltage (V) 400/415
Impulse Withstand Voltage (kV/1.2µS) 4
Product Type Miniature Circuit Breaker
Brand ABB
Series S202C
Ambient Temperature -25 to 55 deg C
Breaking Capacity 10 kA at 415 VAC
Collection S202C
Curve Type C
Degree of Pollution IP2
Degree of Protection IP20
Depth 70 mm
Electrical Durability 10000 Cycles
Height 86 mm
Impulse Voltage 4 kV
Number of Poles 2
Operational Temperature -25 to 55 deg C
Rated Current 6 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 4 kV
Rated Voltage 400/415 VAC
Standards and Approvals IEC/EN 60898-1
Trip Curve C Curve
Width 18 mm
