<p>The S300P series MCB is a robust solution designed to meet the demanding needs of industrial and commercial electrical systems. With its Rated Current of 25 A, this Miniature Circuit Breaker (MCB) ensures reliable protection against overloads and short circuits, safeguarding your electrical installations effectively.</p><p>Engineered for resilience, it boasts a Rated Impulse Withstand Voltage of 6 kV and a Rated Insulation Voltage of 500 V. This makes it well-suited for environments where electrical surges are prevalent. The device operates efficiently at a Rated Voltage of 415 VAC, ensuring compatibility with standard Australian power systems.</p><p>One notable feature is its Breaking Capacity of 15 kA, which provides substantial fault current interruption capability. Complementing this is the Short Circuit Capacity rated at an impressive 25 kA, ensuring high performance in critical situations.</p><p>The MCB&#39;s Degree of Protection ranges from IP20 to IP40, offering flexibility depending on installation requirements. Its Screw Clamp terminal type supports secure connections with a Tightening Torque specification of 2.8 N-m for optimal contact reliability.</p><p>In terms of dimensions, the MCB has a compact footprint with a Width of 70 mm, Height of 88 mm, and Depth measuring at 69 mm. These dimensions facilitate easy integration into existing panels or new setups via DIN Rail mounting.</p><p>Safety standards are paramount; thus, this product adheres to CSA 22.2 No. 235, IEC/EN 60898-1, IEC/EN 60947-2 as well as UL1077 standards—ensuring compliance and peace of mind during operation.</p><p>With Electrical Durability rated at an extensive lifespan of up to 20000 cycles and operational across frequencies between 50/60 Hz—the S300P series promises longevity coupled with consistent performance under varying conditions.</p><p>Designed for versatility in application settings—it accommodates any Mounting Position while featuring an Arbitrary Power Supply Connection approach—simplifying installation processes significantly regardless if retrofitting or deploying within new projects alike!</p><p>Its Curve Type C characteristic means it&#39;s optimized primarily towards general-purpose applications where moderate inrush currents occur frequently without tripping unnecessarily—ideal when considering diverse load types often encountered commercially today!</p><p>Furthermore—the housing color RAL7039 Grey adds aesthetic uniformity particularly useful when blending seamlessly amidst other equipment present onsite already installed previously perhaps?</p><p>Capable across extreme temperatures ranging from -40&#176;C up through +70&#176;C operationally speaking—and featuring Dielectric Test Voltage capacity reaching levels upwards around approximately two kilovolts—you can trust these units perform reliably even under harshest environmental conditions imaginable!</p><p>Weighing only about half kilogram (~0&#183;496kg), each unit remains relatively lightweight yet packed full features necessary ensure continued success whatever task demands might arise ahead potentially!</p>
