<p>When it comes to selecting a reliable Molded Case Circuit Breaker (MCCB) for your industrial or commercial projects, understanding the specifications is key. This MCCB is designed with precision and built to meet the demands of various electrical applications.</p><p>With a rated current of 100 A, this MCCB ensures efficient performance in protecting your circuits from overloads and short circuits. It operates at both AC and DC voltages, with a rated voltage capacity of 690 VAC and 500 VDC. The device’s robust design includes a rated impulse withstand voltage of 8 kV and an insulation voltage rating of 800 V, providing excellent protection against transient overvoltages.</p><p>This model features a thermal-magnetic (TM) release type with a TMD trip unit, ensuring precise operation under varying load conditions. Its power loss is minimal at just 5.6 W, contributing to energy efficiency in your installations.</p><p>The MCCB boasts four poles, offering comprehensive circuit protection across multiple phases. With an impressive breaking capacity of 36 kA, it can handle significant fault currents without compromising safety or performance. The connection type is front-facing with bolt terminals for secure installation.</p><p>In terms of physical dimensions, the MCCB has a width of 140 mm and weighs in at just 2.1 kg—making it compact yet sturdy enough for demanding environments. Its degree of protection is IP20, suitable for indoor use where dust ingress needs to be minimized but not entirely sealed from water exposure.</p><p>Conforming to IEC60947-2 standards ensures that this MCCB meets international safety and performance benchmarks—giving you peace of mind regarding compliance and reliability.</p><p>The product supports frequencies ranging between 50/60 Hz and offers compatibility with XT3N systems—a versatile choice for diverse applications within its current setting range from 70-100 A. Additionally, the main circuit connecting capacity ranges from 85 to192 sq-mm accommodating various conductor sizes seamlessly.</p><p>Whether you&#39;re upgrading existing infrastructure or embarking on new projects requiring dependable circuit breakers that stand up to rigorous conditions while maintaining operational integrity—this MCCB delivers on all fronts without compromise.</p>
