SCHMERSAL AZ 13 KUPOSITIVE-OPERATIONDOOR CONTACT 101060279

Product Code: 101060279

Technical Specifications

Brand SCHMERSAL
Actuating Force (N) 1.6
Actuating Stroke (mm) 7
Cable Entry Single Conductor Version with Connecting Funnel
Contact Material Silver-plated Cu Rivets
Degree of Protection IP20
Depth (mm) 19
Height (mm) 55
Housing Material Plastic, Glass-fibre Reinforced Thermoplastic, Self-extinguishing
Maximum Ambient Temperature (°C) 70
Maximum Fuse Rating 6 A gG D-fuse
Minimum Ambient Temperature (°C) -30
Minimum Mechanical Life 1000000 Operations
Minimum Positive Break Force (N) 10
No. of Safety Contacts 1
Rated Insulation Voltage (V) 500
Rated Operational Current AC-15 (A) 2
Rated Operational Current DC-13 (A) 2
Rated Operational Voltage AC-15 (V) 230V AC
Rated Operational Voltage DC-13 (V) 200V DC
Standards and Approvals EN 81-20
Switching Element Opener (NC)
Switching Principle Self-cleaning Pressure Contact
Termination Screw Terminals M20 x 1.5
Thermal Test Current (A) 4
Utilisation Category DC-13
Width (mm) 44
