SCHMERSAL SE-SET VER.2.0 10.5M/20M SENSOR SET SAFETY-RELATED TACTILE SENSOR 101181969

Product Code: 101181969

In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Actuator Type Roller plunger
Enclosure Material Metal, zinc die-cast
Maximum Ambient Temperature (°C) 80
Maximum Temperature (°C) 170
Minimum Ambient Temperature (°C) -30
Minimum Temperature (°C) -50
Gross Weight (g) 190
Net Weight (g) 20
Brand SCHMERSAL
Product Type Sensor
Series SE-SET
EAN 4030660000000
eCl@ss Number, Version 9.0 27-27-26-01
ETIM 7.0 EC000030
ETIM 6.0 EC000030
eCl@ss Number, Version 11.0 27-27-26-01
Contact Material Silver
Maximum Actuating Speed (m/s) 0.2
Maximum Cable Cross Section (mm²) 1.5
Maximum Fuse Rating 4 A gG D-fuse to DIN EN 60269-1
Minimum Cable Cross Section (mm²) 0.75
Minimum Mechanical Life 10000000 Operations
No. of Safety Contacts 3
Rated Impulse Withstand Voltage (kV) 6
Rated Insulation Voltage (V) 300
Rated Short-circuit Current (A) 100
Switching Element Opener (NC)
Switching Principle Slow action
Terminal Type Screw terminals M20 x 1.5
Utilisation Category DC-13 | AC-15
Sensor Length (mm) 13
Sensor Height (mm) 116.6
Degree of Protection IP67
Standards EN 81-20 / EN 81-50

Description

Enhance machine safety with the Schmersal SE-SET series safety-related tactile sensor. Constructed from durable polyurethane, this safety edge is designed to provide reliable protection and easy integration into your safety system. It features a transmitter cable length of 10.5 meters and a receiver cable length of 20 meters, ensuring flexible installation options for various machinery configurations. Trust in Schmersal's commitment to machine safety with this essential component in your hazard prevention strategy.
