Specifications

Housing Material	Glass-fibre, Reinforced Thermoplastic
Maximum Ambient Temperature (°C)	70
Minimum Ambient Temperature (°C)	-25
Installation Conditions	Not Flush
Direction of Motion	Head-on to the Active Surface
Brand	SCHMERSAL
Recommended Safety Switchgear	SRB-E-301ST
Recommended Actuator	EX-BPS 250-3G/D
Actuating Element	Magnet
Maximum Storage Temperature (°C)	70
Maximum Switching Capacity (W)	1
Maximum Switching Current (A)	0.1
Maximum Switching Frequency (Hz)	5
Maximum Switching Voltage DC (V)	24
Minimum Storage Temperature (°C)	-25
No. of Cables	6
No. of Normally-open Contacts	1
Resistance to Shock (g/ms)	30g / 11ms
Resistance to Vibrations	10 ... 55Hz, Amplitude 1mm
Termination	Cable
Wire Cross Section (mm²)	0.25mm² (Diameter)
Sensor Length (mm)	13
Sensor Width (mm)	33
Sensor Height (mm)	25
Degree of Protection	IP67
Standards and Approvals	EN ISO 13849-1, EN IEC 60079-0
Explosion Protection Category	3D
