Brand	ABB
Design of Control Element	Toggle
Magnetic - I3 (A)	625 - 1250
Main Circuit Electrical Connection	Bolt Connection
Main Current Circuit Connection Position	Front Side
MCCB Type	XT4 Frame
Overload Release Current Setting (A)	87.5
Rated Instantaneous Short-Circuit Current - Ii (A)	625
Thermal (0.7 to 1 x In) - I1 (A)	87.5 - 125
Trip Unit - Thermal Magnetic	TMA
Tripping Unit	TMA
Breaking Capacity (kA)	70
Breaking Capacity 415V AC - Icu (kA)	70
Current Rating (A)	125
Degree of Protection	IP20
EAN	8015644022662
No. of Poles	4
Poles	4P
Power Loss (W)	7.44
Rated Current (A)	125
Rated Uninterrupted Current - Iu (A)	160
Rated Voltage (V)	690
Size of Frame	XT4
Trip Unit	TMA

Moulded Case Circuit Breakers

ABB XT4H 160 TMA 125-1250 4P F F INN=100% 1SDA068360R1
