Product Code: 942 076-998-001

Optimize your network performance with the Hirschmann MSP30 series switch, featuring 24 Fast Ethernet ports with PoE+ capabilities and an additional 4 Gigabit Ethernet ports for high-speed connectivity. Designed for reliability in industrial environments, this switch operates efficiently on a 24 V DC power supply (ranging from 18 to 32 V) and maintains functionality in temperatures ranging from 0 to +60 degrees Celsius. With an IP20 rating, the MSP30 ensures robust protection against particulates, making it a solid choice for your network solutions within demanding operational conditions.

Brand	HIRSCHMANN
Maximum Temperature (°C)	60
Minimum Temperature (°C)	0
No. of 100Mb Ports	24
No. of 1GB Ports	4
No. of Ethernet Ports	28
Nominal Power (W)	18
Rated Maximum Operational Voltage DC (V)	32
Rated Minimum Operational Voltage DC (V)	18
Degree of Protection	IP20
Dimensions (mm)	148H x 391W x 142D
Mounting Type	DIN Rail
No. of Ports	24 x Fast Ethernet, 4 x Gigabit Ethernet
Operational Temperature Range (°C)	0 to +60
Power Consumption (W)	18
Rated Voltage DC (V)	24
Series	MSP30
Standards and Approvals	CE, FCC, EN61131, EN60950
