ABB ATB502E ALUMINIUM TERMINAL BLOCK EARTH 4 CONNECTIONS CABLE 50mm²

Product Code: ATB502E

The Aluminium Terminal Block is designed for earth connections and has 4 connection points. It is suitable for cable sizes up to 50mm² and comes in a yellow/green colour. The nominal current for copper cables is 160A and for aluminium cables is 145A. The block has a nominal insulation voltage of 800V. This terminal block can be used with both copper and aluminium cables. It features tin plating, which helps prevent galvanic reactions. Additionally, it has an internal barrier that allows for the connection of both aluminium and copper cables to a single block. The screw head size of the terminal block is 5mm, making it easy to install on a DIN rail.

Technical Specifications

Brand ABB
Colour Yellow/Green
Maximum Cable Cross Section (mm²) 50
No. of Connections 4
Nominal Current (A) 160 (Cu)/145 (AL)
Nominal Insulation Voltage (V) 800
Screw Head Size (mm) 5
Tightening Torque (Nm) 4 (2.5-4mm²)/12 (6-50mm²)
