ABB MCRA031AT7 MINI CONTACTOR RELAY 3NO+1NC 240V 50/60HZ MCRA031AT7

Product Code: MCRA031AT7

  • Compact design, ideal for installations with limited space Four poles for versatile and efficient electrical switching Secure and convenient electrical connections Options for wall or rail mounting to accommodate different installations needs
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Mounting Type DIN Rail
Brand ABB
Product Type Mini Contactor
Series M
Actuating Voltage Type AC
Auxiliary Contacts 3NO, 1NC
Connection Type Screw Connection for Auxiliary Circuit
No. of Normally-closed Auxiliary Contacts 1
No. of Normally-open Auxiliary Contacts 3
No. of Poles 4
Operating Voltage AC (V) 690
Operating Voltage DC (V) 440
Operating Voltage Type AC
Rated Control Circuit Voltage AC (V) 240
Rated Control Supply Voltage AC (V) 240
Rated Frequency (Hz) 50/60
Rated Impulse Withstand Voltage (kV) 6
Rated Insulation Voltage (V) 750
Rated Operational Current (A) 6
Rated Operational Current AC-15 240V (A) 6
Rated Operational Current AC-15 400V (A) 4
Rated Operational Voltage AC (V) 690
Rated Supply Voltage AC (V) 240
Terminal Type Screw Terminals
Dimensions (mm) 45W x 48H x 56D
Degree of Protection IP20

Description

The MCRA031AT7 mini contactor relay is a dimension optimized 4 pole contactor relay with screw terminals. This device is a great solution when high performances are needed but the space is limited. Mini contactors are used in residential buldings, commercial buildings and industrial applications for switching of control signals up to 6 A / 240 V (AC-15). The product is suitable for wall or rail mounting.
