ABB CA4-22U AUXILIARY CONTACT BLOCK CA422U

Product Code: CA422U

In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Mounting Type Front Fastening
Model Clip-on
Suitable For AF09 - AF16
Brand ABB
Product Type Accessory
Auxiliary Contacts 2NO/2NC
Connection Type Screw Connection
No. of Normally-closed Contacts 2
No. of Normally-open Contacts 2
Rated Frequency (Hz) 50/60
Rated Impulse Withstand Voltage (kV) 6
Rated Insulation Voltage (V) 690
Rated Operational Current AC-15 230V (A) 4
Rated Operational Voltage AC (V) 24 - 690
Terminal Type Screw
Dimensions (mm) 43W x 43H x 39.5D

Description

CA4-22U is a 4-pole front mounted auxiliary contact block equipped with screw terminals. CA4-..U version offers terminal assortment matching the marking of 3-pole AF(C)09..16(Z)(B)-30-01 contactors. CA4-22U is available with 2 N.O. and 2 N.C. instantaneous contacts for standard industrial environments.
