ABB NF80E-11 24-60V50/60HZ 20-60VDC CONTACTOR RELAY NF80E11

Product Code: NF80E11

  • Enables operation within a broad voltage spectrum Efficient built-in surge suppression Configured with eight poles for efficient switching in auxiliary and control circuits Operable with both AC and DC in the control circuit
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Mounting Type DIN Rail / Screw
Storage Temperature (°C) -60 to +80
Operational Temperature Range (°C) -40 to +70
Brand ABB
Product Type NF Contactor Relay
Actuating Voltage Type AC/DC
Auxiliary Contacts 8NO
Connection Type Screw Connection for Auxiliary Circuit
No. of Normally-open Auxiliary Contacts 8
No. of Poles 8
Operating Voltage AC (V) 690
Rated Control Circuit Voltage AC (V) 24 - 60
Rated Control Circuit Voltage DC (V) 20 - 60
Rated Control Supply Voltage AC (V) 24
Rated Control Supply Voltage DC (V) 20
Rated Impulse Withstand Voltage (kV) 6
Rated Insulation Voltage (V) 690
Rated Operational Current (A) 3
Rated Operational Current AC-15 400V (A) 3
Rated Operational Voltage AC (V) 690
Rated Supply Voltage AC (V) 24
Terminal Type Screw Terminals
Dimensions (mm) 45W x 86H x 110.5D
Degree of Protection IP20

Description

NF contactor relays are used for switching auxiliary and control circuits. NF contactor relays include an electronic coil interface accepting a wide control voltage Uc min. ... Uc max. Only four coils cover control voltages between 24...500 V 50/60 Hz or 20...500 V DC. NF contactor relays can manage large control voltage variations. One coil can be used for different control voltages used worldwide without any coil change. NF contactor relays have built-in surge protection and do not require additional surge suppressors. - Poles: 8-pole contactor relays - Control Circuit: AC or DC operated - Accessories: a wide range of Accessories is available. Note: NF..E-11 not suitable for a direct control by PLC-output. NF..E-11 type available in some countries: please consult your ABB representative.
