ELKO DIN CONTACTOR, 4P, 25A-AC14NC ,24V AC/DC2 MOD. WIDE , DIN MTG. VS425-04/24V

Product Code: VS425-04/24V

  • 4NC contact type, 25A (AC1), 24V AC/DC Compact: 2 modules wide (35mm) IP20 protection for safety Versatile: Suitable for resistive loads and motors Easy DIN Rail mounting
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Modules - Width 17.5 mm 2
Mounting Type DIN Rail
Operational Temperature Range (°C) -5 to 55
Storage Temperature Range (°C) -30 to 80
Brand ELKO
Product Type DIN Contactor
Series VS
Dielectrical Strength (kV) 4
No. of Normally-closed Contacts 4
No. of Poles 4
Rated Insulation Voltage (V) 440
Rated Operational Current AC-1 (A) 25
Rated Supply Voltage AC/DC (V) 24
Dimensions (mm) 35W x 85H x 60D
Weight (kg) 0.213
Degree of Protection IP20
Standards and Approvals IEC 60947-4-1, IEC 60947-5-1, IEC 61095, EN 60947-4-1, EN 60947-5-1, EN 61095, EN 60947-1

Description

The Din Contactor is a 4NC contact type with a current rating of 25A (AC1) and a control voltage of 24V AC/DC. It has a width of 2 modules, with each module being 17.5mm wide. The contactor provides IP20 protection and is designed for switching resistive loads and three-phase induction motors. It is suitable for various applications including heating, lighting, hot water, and storage heating. The Din Contactor can be easily mounted on a DIN Rail.
