IPD TCP100M160L FUSE LINK 160A 415VAC OFF-SET TAG MOTOR RATED 94mm FIXING CENTRES 80kA BTCP42V100M160

The TCP_L offset bolted tags-2hole fixing BS fuse links (available in sizes A1 to A4) are designed for general industrial applications. They comply with the standard BS88-2 and IEC 60269-2. These fuse links have a breaking range and utilisation category of gM, providing good peak and let-through current limitation. The breaking capacity is AC: ASTA 20 certified up to 80 kA. They have a rated current of 160A and operate at a voltage of 415VAC.
