MERSEN OT150 FUSE LINK 150A 250VAC/DC UL CLASS K-5 40X111mm BLADE

Product Code: OT150

  • - Easy to read imprint label for quick recognition and replacement - Low cost for high protection value - Lowest cost protection for circuits serving non-inductive loads
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Body Style Blade
Brand MERSEN
Product Type UL North American
Functionality General Purpose
Fuse Class Class K-5
Interrupting Rating AC (kA) 50
Interrupting Rating DC (kA) 20
Rated Current (A) 150
Rated Voltage AC/DC (V) 250
Body Size (mm) 40 x 111

Description

The One-Time OT general purpose fuses offer affordable protection for feeder and branch-circuits that supply lighting, heating, and other non-motor loads. These fuses have a voltage rating of 250V AC/DC and a rated current of 150A. They are capable of safely interrupting short circuit currents up to 50kA/AC and 20kA/DC in all ratings.
