IPD FUSE LINK 25A 415VAC 80kA F1 CLIP-IN BS88 TYPE MOTOR RATED NS20M25

Product Code: NS20M25

NS_M_ Clip-in (F1) BS fuse links are motor start application-specific fuses. They adhere to the standard BS88-1 & 6 and IEC 60269-2. The breaking range and utilization categories are gG -gM. These fuses have a breaking capacity of AC: ASTA 20 certified to 80 kA. The rated current is 25A, and the voltages are 415VAC/240VDC.

Technical Specifications

Brand IPD
Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Connection Type Clip-In
Fuse Construction Type F1
Pack Quantity 10
Rated Current (A) 25
Rated Voltage AC (V) 415
Rated Voltage DC (V) 240
Standards and Approvals IEC 60269, BS88 Part 6
Suitable Fuse Holder SC20/S32
Total Length (mm) 59
Utilisation Category gG/gM
