IPD TIA32L FUSE LINK 32A 415VAC OFF-SET TAG 73mm FIXING CENTRES 80kA USE IN RS32/63,RSM

Product Code: TIA32L

The TIA offset bolted tags-2 hole fixing BS fuse link is a specially designed product for protecting industrial and general purpose applications. It falls under the gG utilization category and has good peak and let-through current limitation. The breaking capacity of this fuse link has been tested up to 80 kA. It is rated for a current of 32A and a voltage of 415VAC.

Technical Specifications

Brand IPD
Body Diameter (mm) 23.0
Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Carton Quantity 10
Diameter (mm) 23
Fixing Centres (mm) 73
Rated Current (A) 32
Rated Voltage AC (V) 415
Utilisation Category gG
